Home > Stainless Steel 316h Stud Bolts
Request For Our Latest Prices On Stainless Steel 316h Stud Bolts in Manama, Bahrain!
Malik Fasteners, a reputable manufacturer and supplier based in Manama, Bahrain, specializes in high-performance Stainless Steel 316H Stud Bolts that are crafted to withstand the tough demands of high-temperature and corrosive industrial settings. Known for their precision engineering and unwavering product quality, the company ensures that their stud bolts meet rigorous international standards. The Stainless Steel 316H, a high-carbon variant of 316, offers enhanced strength at elevated temperatures, making these bolts perfect for heavy-duty applications. Malik Fasteners caters to vital industries like petrochemical, power generation, chemical processing, and offshore sectors, providing reliable fastening solutions built for durability and long-lasting performance.
Stainless Steel 316H Stud Bolts are made up mainly of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), with a higher carbon content that boosts their strength at high temperatures. This unique composition grants them excellent resistance to corrosion, pitting, and oxidation. On the mechanical side, SS 316H boasts superior tensile strength, improved creep resistance, and solid yield strength, particularly in high-temperature conditions. The increased carbon content ensures better structural stability under thermal stress, making 316H stud bolts a trustworthy choice for demanding industrial environments that require durability, heat resistance, and mechanical reliability.
| Fasteners Material Specification | ASTM A194, ASME SA193, UNS S31609 Bolts |
|---|---|
| Standard | DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards |
| Fasteners/ Bolts Size | M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160 |
| Length | 3 mm to 200 mm |
| Bolts, Studs Threads: | METRIC, BSW, BSF, UNC, UNF or as required |
| SS 316h Fasteners Standard: | ANSI – American National Standards Institute
|
| Source of raw materials | Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc. |
| SCOPE OF MANUFACTURE |
|
| Fasteners In Form of: | Hex, Square, Round, Threading as per Gauge Etc. |
| Head drive: | Phillips, Slotted, Phillips/Slot, Six-Lobe, etc |
| bolting Test Certificate: | Manufacturer Test Certificate as per EN 10204 / 3.1 |
| Fasteners finishing: | Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET |
| Production process | M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element |
| bolting materials Surface Coating: |
|
| Popular Types of SS 316h Bolts | Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Counter sunk Bolts etc. |
| Popular Types of SS 316h Nut | Hex Head Nut, Eye Nut, Dome Nut, Wing Nut, T Nut, Panel Nut, Lock Nut, Coupling Nut, Square Nut, Acorn Nut etc. |
| Popular Types of SS 316h Screw | Hex Head Cap Screws, Socket Set Screws, Anchor Screws, Blind Rivet, Socket Head Screws, Concrete Screws, Shoulder Screws, Panel Screws, Threaded Screws, Machine Screws etc. |
| Popular Types of SS 316h Washer | Machine Washers, Flat Washer, Star Washers, Sealing Washer, Lock Washer, Split Washer etc. |
| Our stockyad location for fast delivery in India | Noida, Bengaluru, Pimpri-Chinchwad, Thiruvananthapuram, Tirunelveli, Vasai, Dhanbad, Chennai, Agra, Nagpur, Hyderabad, Kolkata, Coimbatore, Pune, Jaipur, Tiruchirappalli, Shivamogga, Ahmedabad, surat, Bhubaneswar, Thane, Nashik |
| Fasteners Packing: | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
|
316H |
Min |
0.04 |
0.04 |
0 |
– |
– |
16.0 |
2.00 |
10.0 |
– |
|
max |
0.10 |
0.10 |
0.75 |
0.045 |
0.03 |
18.0 |
3.00 |
14.0 |
– |
|
Grade |
Tensile Str
(MPa) min |
Yield Str
0.2% Proof
(MPa) min |
Elong
(% in 50mm) min |
Hardness |
|
|
Rockwell B (HR B) max |
Brinell (HB) max |
||||
|
316H |
515 |
205 |
40 |
95 |
217 |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Stainless Steel 316H Stud Bolts find their place in high-temperature and corrosive environments where strength and reliability are non-negotiable. They’re commonly used in heat exchangers, boilers, pressure vessels, and refinery equipment thanks to their superior thermal stability. Industries such as petrochemical, oil and gas, chemical processing, and power generation depend on 316H stud bolts for secure fastening solutions that stand the test of time.
At Malik Fasteners, we ensure that our Stainless Steel 316H stud bolts are installed with the utmost care to maintain their quality and performance. Our durable packaging solutions protect bolts from damage using durable materials and safe methods. Each package is clearly labelled with detailed ingredient information for easy identification and proper inventory management. Whether it’s small orders or large shipments, our careful packaging ensures that your 316H stud bolts arrive in perfect condition, ready for demanding use.
Malik Fasteners is a leading manufacturer and supplier of high-quality fasteners in Manama, Bahrain, with over 8 years of experience serving global industries.
